In Stock China Supplier CNC Plate drilling Equipment producing
machines DPD1016/2016/DPD3016
1.High quality, Fair Price, Fast Delivery.
2.OEM Service, Trail Order,Buyer Label Service
3.The Color, The logo, The package according to your request,
4.We are the Manufacturer,We have many engineers for the solutions for the new market to
keep the trend of the world.
| Name | China Supplier CNC Plate drilling Equipment producing machines |
| Model | DPD1016/2016/2020/3016/3030/4040 |
| Brand | SOLTERRA |
| Certificates | ISO9001:2008,SGS |
| Warranty | The Warranty time is one year, Engineers available to the service |
| Delivery time | Within 15 working days after receiving the down payments |
| Payment terms | L/C,T/T,Western union |
Machine Description
This Plate drilling machine is mainly used in the fields of Steel Structure,Bridge,Electric-communication
Tower, Heat Power Station,and Boiler etc, for the drilling process
of connectin plate, foundation plate, terminal plate, template,
flange plate,structual componet etc.
1.The machine is mainly composed of base, gantry, drilling unit,
exchangeable worktable, chip removal system, electric system,
hydraulic system and centralized lubricating system etc.
2.There are two exchangeable worktables in the machine, while the workpiece on one worktable is being
drilled, the other worktable can be moved out to unload the
finished workpiece and load a new workpiece. These exchangeable
worktables can greatly reduce the loading and unloading time and
improve the production efficiency.
3.This machine used stroke self-controlled drilling unit. Rapid feeding,working feed and rapid withdrawing are transformed
automatically without presetting any parameters manually such as
the length of the drill and the thickness of the workpiece before
operating, so that the machine is easy to operate.
5.Workpieces are clamped tightly by hydraulic clamps, For small
work pieces the machine can clamp four groups together so as to
reduce the preparation period of production and increase the
efficiency.
6.The software of host computer is humanized designed. The machine’s running data can be shown directly on the real time
monitor and I/O monitor interfaces.
7.The machine uses centralized lubricating system to make sure all
the function parts being well lubricated thus improve the
performance and extend the lifetime of the machine.
Technical Parameter:
Model | DPD1016 |
Size of workpiece | Thickness of workpiece(mm) | Max. 80 |
Width x Length(mm) | 1000×1650 (One Piece) |
825×1000 (Two pieces) |
500×825 (Four pieces ) |
Drilling spindle | Quick-change drill chuck | Morse 3# 4# |
Diameter of drilling head(mm) | Φ12-Φ50 |
The mode of speed adjustment | Transducer stepless speed adjustment |
Rotate speed(r/min) | 120-560 |
Stroke(mm) | 180 |
Processing feeding | Hydraulic steeples speed adjustment |
Hydraulic clamping | Thickness of clamping (mm) | 15-80 |
Quantity of clamping cylinder | 12 |
Clamping power(kN) | 7.5 |
Start-up clamping | Foot-switch |
Cooling fiuid | Mode | Forcing cycle |
Volume(L) | Appro.100 |
Hydraulic system | Clamping pressure(MPa) | 7.5 |
Feeding pressure(MPa) | 2 |
Volume of oil tank(L) | 120 |
Air Pressure | Source of compressed air(MPa) | 0.4 |
Motor | Spindle(kW) | 5.5 |
Total power | kW | 15 |
Overall dimensions | Length x Width x Height | 3800×2200×2780 |
Weight
| Main Body(kg) | Approx 4000 |
Chip Removal System(kg) | 400 |
Machine Images
Packaging & Shipping
Package
Our Services
Service for Customer
Certificate
Contact Information
Question 1. Are you a Manufacturer or a trading company?
Answer 1. We are not a trading company,We are the top Machine
Manufacturer,Which involves Raw materail casting,Machine body
processing,Machine assembling,Painting,Machine quality Inspecting
and etc.
Q 2. What is the minimum quantity for order ?
A2: Normaly One Set. and We will give some discounts if you can buy
one complete set of Machine.
Q3. Do you have stock product ready to deliver?
A 3. We have many machines in stock, So We can guarantee the fast
delivery time and make sure you can check the machine on
LIVE-DEMONSTRATION at any time.
Q4. How do you deliver the finished products?
A 4, For FCL, We delivered by Sea
For LCL, We delivered by Sea and by Plane for only urgent
requirement
For Spare Parts,We delivered by Courier,TNT, FEDEX,DHL,UPS,EMS, and
Etc.
Q5,How can you guarantee the after-sales service?
A 5, We have a first-class engineers for the machine installation,
tranining, and after-sales, we also have branch office in ovesea to
keep the good after-sales service,They have a professional work
team with exquisite experience.
Q6, What's delivery time for the machines.
A 6, We will arrange the shipment within 20 days after receiving
the payment.
Q7, Do you inspect the finished products?
A7, Yes, Each step of production products will be camed out
inspection by QC department before shipping
