China Suppliers CNC Angle Line Punching Marking Cutting Machinery
Price
This Machine is popular for processing angle steels and tower
industry
1.High quality, Fair Price, Fast Delivery.
2.OEM Service, Trail Order
3.The Color, The logo, The package according to your request,
4.We are the Manufacturer,We have many engineers for the solutions for the new market to
keep the trend of the world.
5.Product Video can be sent to you for reference
Jinan Liaoyuan Machine Co.,Ltd is a fast growing company dedicate to offer Iron tower and steel
struction equipment.
Brief Product Introduction
| Name | 2018 CNC ANGLE LINE PUNCHING MARKING SHEARING MACHINERY PRICE |
| Model | APL-1412 |
| Brand | SOLTERRA |
| Warranty | The Warranty Time is One year, Engineers available to the Service |
| Certificates | ISO9001,SGS |
| Delivery time | Within 6 weeks after confirming the order |
| Payment terms | L/C,T/T |
As a factory,we will give you the highest quality and the
competitive price.
We are looking for the agent of our machines all over the world.
Item:APL-1412
This Series production lines are professional automatic equipments
for typing,marking,punching and cutting if angle steel
of electric power and telecommnucaiton angle steel tower.
Processing Size: Steel type L63X63X4,length with 16M. It includes
6 parts: Material-applying parts,feeding part,principal part,
finished production conveyor part, hydraulic power part,electrical
control part.
Equipment Features
1) CNC control, servo motor drive and hydraulic power offer high efficiency and stable working
accuracy.
2) Key hydraulic pneumatic and electically elements are imported
from Gemany, Japan, South Korea etc., such as Panasonic servo motor
and Mitsubishi PLC.
3) Marking, punching and shearing are all automatically operated.
4) Computer adopts friendly interface and supports manual
programming. Easy to operate.
5) Marking unit adopts a closed frame with good rigidity; different
punching toolings can be intalled accroding to needs.
6) Hydraulic pipeline is ferrule connected, ensuring high level of
working security.
7) Workpiece infeeded by CNC carriage with high accuracy.
8) Double bladder accumulator provides sufficient power.
Advantages
- The machine is composed of transverse conveyor,rotating loading
system,infeed conveyor,CNC infeed carriage,marking unit,shearing
unit,unloading conveyor as well as hydraulic,electrical and
pneumatic system,etc.
- Veasatile triple tooling on each side which can install three kinds
of punches with different diameters.Versatile triple tooling can
move together controlled by CNC which is to change the punching
stadia.
- Double-blade shearing ensures perfect cutting section.The clearance
can be conveniently adjusted.
- Marking unit adopts a closed frame with good rigidity.Four sets of
character boxes are fixed on the marking unit which can be selected
by program.Marking stadia can be at will.
- The workpiece is infeeded by the CNC carriage with high positioning
precision.The infeed carriage is driven by servo motor.The
photoelectric encoder feds back the information.Closed loop
control.The clamp arm moves up and down with high rigidity.It is
driven by ball screw and guided by linear guideway.
- The support device of the ounching unit is driven up and down by
hydraulic cylinder.
- The rotating loading system is driven by the reducer with high
working stability.
- The hydraulic system mainly serves for
punching,shearing,marking,marking device movement,pressing and
supporting workpiece,and tansposition of character boxes.The
hydraulic pipeline is ferrule connect.
Main Technical Specifications
| Model | APL-2020 |
| Angle Size (mm) | 63×63×4~200×20×20 |
Max. punching capability Diameter×Thickness (mm) | Φ26×20 |
| Nominal punching force (kN) | 1000 |
| Marking force (kN) | 550 |
| Shearing force (kN) | 1550 |
| Max. length of workpiece (m) | 14 |
| Max. lenght of finished product(m) | 12 |
| No. of punches on every side | 3 |
| No. of character group | 4 |
| Dimensions of character (mm) | 14×10×19 |
| No. of CNC axis | 3 |
| Shearing mode | Double shearing |
| Feeding speed (m/min) | 0-60 stepless adjustable |
| Processing precision | GB/T2694-2003 standard |
| Programming model | Keyboard enter, RS232 interface enter, CAD input |
| Overal dimensions (m) | 32×7×2.6 |
| Net weight (t) | 20 |
Machine Images
Processing Object
15-25 days of theoretical and practical study are provided to the
customer’s two technicians (an electrician, a mechanical
maintenance).
1) Will send special electrical and mechanical engineers implement
one-on-one type training and coaching; ensure learning personnel
grasp basic maintenance knowledge and operation.
2) After training will have a test, if qualified will issue the
equipment operation and maintenance certificate from our company to
the operators
Global Customers visit Jinan Liaoyuan Machine
Fully ISO Quality Management System Approved, For more informaiton
about
the certificate,please feel free to contact me!!!
Contact information
We need to know the angle size of the machine, and then We will
recommend suitable model for you.
